Sintered Filter Plate
Sintered Filter Plate Technical Parameter
Raw Material: SS 316L, SS 304
Filter Rating Range: 0.5 Micron ~ 2000 Microns
Filter Efficiency: > 99.99 %
Operation Temperature: ≤ 816 ℃
Length: ≤ 1200 mm
Width: ≤ 1000 mm
Regular Size (Length*Width): 500 mm*500 mm, 1000 mm*500 mm,1000 mm*1000 mm, 1200 mm*1000 mm or others
Thickness: 0.5 mm,1 mm,1.5 mm,2 mm,3 mm,5 mm or others
Sintered Filter Plate Feature
1. Sintered filter plate is made from multilayer wire mesh
2. Sintered filter plate is sintered in a high temperature vacuum furnace
3. Sintered filter plate is surface filtration
4. Sintered filter plate is good for backwash because the pore passage of wire mesh aperture is very smooth
5. Sintered filter plate has uniform pore size distribution
6. High compression strength
7. High mechanical strength
8. High rigidity
9. High abrasion resistance
10. High durability against most liquids, gases and aggressive steam
11. High temperature resistance
12. High filter rating accuracy
13. High filter efficiency
14. High corrosion resistance
15. Washable and Cleanable
17. Long service life
Polyester filtration, polymer filtration, membrane filtration, oil filtration, steam filtration, gas filtration, powder filtration, liquid filtration, water filtration, beverages filtration, detergent filtration, solvents filtration, medicine filtration, pharmaceutical industry, petroleum industry, biological industry, chemical industry, chemical fiber industry, food industry
XINXIANG ZWEN FILTER CO.,LTD produces sintered filter, sintered fiber felt filter, sintered metal filter, sintered porous filter, sintered powder filter, sintered wire mesh filter, sintered filter cartridge, sintered filter disc, sintered filter element, sintered filter pipe, sintered filter plate, sintered filter rod, sintered filter sheet, and sintered filter tube.
XINXIANG ZWEN FILTER CO.,LTD has advanced sintering equipment, advanced welding equipment and a high level of skilled workers.
XINXIANG ZWEN FILTER CO.,LTD has passed ISO 9001:2008 quality management system and SGS audit test.
XINXIANG ZWEN FILTER CO.,LTD main markets are European market and North American market.
XINXIANG ZWEN FILTER CO.,LTD Key Clients: Parker, GKN, SIEMENS, MAHLE.
