Sintered Filter Rod
Sintered Filter Rod

Sintered Filter Rod

Sintered Filter Rod Technical Data

Raw Material: SS 316L,Titanium

Filter Rating Range: 0.22 Micron ~ 100 Microns

Operation Temperature:  816

Outside Diameter: 12 mm, 25 mm, 30 mm, 50 mm, 60 mm, 65 mm, 80 mm, 90 mm, 100 mm

Length: 254 mm, 508 mm, 762 mm, 1016 mm or others

Gasket: PTFE, Viton, Silicone, Buna-n, EPDM

Connector/Fitting/Adaptor:

1. DOE

2. Code 2 (226+Flat End)

3. Code 3 (222+Flat End)

4. Code 7 (226+Fin End)

5. Code 8 (222+Fin End)

6. Thread (NPT,BSP,G,M,R)

7. Flange

8. Special customization


Sintered Filter Rod Feature

1. Sintered filter rod is made from stainless steel powder particle or titanium powder particle

2. Sintered filter rod is sintered in a high temperature vacuum furnace

3. Sintered filter rod is surface filtration and depth filtration

4. Sintered filter rod has narrow pore size distribution

5. High dirt holding capacity

6. Good porosity

7. High filter rating accuracy

8. The effect of filtration is good

9. High filter efficiency

10. Good permeability

11. Pressure loss is low in filtration process

12. High flow rate at low differential pressure

13. High compression strength

14. High mechanical strength

15. High abrasion resistance

16. High durability against most liquids, gases and aggressive steam

17. High temperature resistance

18. High corrosion resistance

19. Backwash

20. Washable and Cleanable

21. Reusable

22. Long service life


Application

1. Steam filtration

2. High temperature liquid filtration

3. High temperature gases filtration

4. Catalysts powders recovery

5. Precoat support filtration


About Us

XINXIANG ZWEN FILTER CO.,LTD  produces sintered filter, sintered fiber felt filter, sintered metal filter, sintered porous filter, sintered powder filter, sintered wire mesh filter, sintered filter cartridge, sintered filter disc, sintered filter element, sintered filter pipe, sintered filter plate, sintered filter rod, sintered filter sheet, and sintered filter tube.


XINXIANG ZWEN FILTER CO.,LTD has advanced sintering equipment, advanced welding equipment and a high level of skilled workers.


XINXIANG ZWEN FILTER CO.,LTD has passed ISO 9001:2008 quality management system and SGS audit test.


XINXIANG ZWEN FILTER CO.,LTD main markets are European market and North American market.


XINXIANG ZWEN FILTER CO.,LTD Key Clients: Parker, GKN, SIEMENTS, MAHLE.
